RUNLEADER HOUR METER ---- Keep an accurate record of engine used for total(TOT) and partial hours(JOB), with ability to program a previous time (INT) for new meter replaced; Do regular maintenance task to determine the time of due(SVC); TOT & JOB hours read up to 999,999 hours;SVC timer range: OFF/5-2000 hours.
RPM METER GAUGE ---- It enable to check and adjust the idle revolution by various of engine firing patterns; Alert channel for revolution exceed reminder; Display the highest RPM hit since the engine started; RPM measurement range: 0-25000RPM,Alert range: 100-25000RPM, Selectable refresh rate: 0.5/1s.
2 BACKLIGHT DISPLAY ---- Bright white backlight will help to use it at night or dim place, you can set the backlight mode by always-on, OFF and automatical mode(OFF default, button to wake up) as request; Red backlight will help to remind the engine RPM exceed and maintenance service time arrival.
MULTIPLE INSTALLTION ---- You can mount it by screw-on,stick-on or snap-in (Panel cut-out size: 2.08x1.57 inches) at any proper position,well-compeleted accessories will keep it fit for different using requirement; One wire hook-up design for engine signal detection with wire shorten or extend (wire length:appox. 68.8 inches).
OTHERS ---- Built in replaceable battery CR2032 with insulation sheet to keep the capacity in good condition during transport; Favorable water and shock resistence by PC display window and back compartment with O ring sealing; Reliable technical support and after-sales service (2 years).
