LED BATTERY POWER METER ---- It is a useful device to help you to know how much battery power have left by 10 LED bars with 3 colors (1 red 2 yellows 7 greens,each bars indicate 10% battery power); It is applicable to 12 to 24V lead acid battery (not trojan) powered machines.
BATTERY STATE OF CHARGE & DISCHARGE ---- It display battery charge status by LED bars step up, and display battery discharge status by LED bars step down. Battery charge delay time: 200s; Battery discharge time: 155s.
LOW BATTERY REMINDER ---- It with ability to let you know when to charge the battery,when battery capacity ≤20%, it will remind you by 1 flashing LED bar,when battery capacity ≤10%, it will remind you by 2 bars flashing alternately.
INSTALLATION ---- Easy to mount it at any proper place by snap-in pannel cut-out size: 45.50mm*22.50mm (1.79 inches*22.50 inch), the attached mounting bracket will keep it more stable; Avaliable 2 kinds of power connection methods: direct power connection and key switch power connection based on easy positive and negative connection; Link the “C” pole with positive(+) as a key step for normal battery power display.
OTHER FEATURES ---- Favorable water resistance by 100% epoxy resin craft up to IP67; Well-compeleted accessories; Excellent after-sales and technical support (2 years warranty)
