MULTIFUNCTIONAL BATTERY METER ---- It is a gauge to let you know how much battery power have left during charge and discharge situation by power percentage and 5 progress bars; Help to track the toal hours of machine,perform the regular maintenance task and advise its arrival status; It also can be a voltage gauge to monitor the real-time voltage and alert the voltage lack or exceed according to your preset value; Applicable battery type: Lead acid, Trojan, LiFePO4, GEL,AGM, 18650 lithium battery;
CAN for DATA TRANSFER ---- This battery power indicator can be exchanged the working data by built-in 2 CAN frames: standard frame(SId) and extended frame(EId), based on your machine with corresponding CAN setup; Default SId ID:ID0X18FF0b50, EId ID: ID0X201.
BACKLIGHT DISPLAY ---- White backlight will help to use it at night or the dim place, you can set the backlight for always-on, OFF and automatical mode as request; Red backlight will remind the battery lower status and voltage exceed or lack.
WATER RESISTANCE ---- It made by 100% epoxy resin craft and whole ABS housing design, which have strong water resistance up to IP68(normal working upon 10 meters underwater).
OTHER FEATURES ---- Hours record by accumulating, maintenance hours for schedule arrangement; Easy to mount it by drill-in and snap-in at any proper place, panel cut-out size: 44.5x44.5mm (1.75x1.75 inches); Working signal connection by attached connection port, the low and high level timing can be selected; Well-compeleted accessories; Excellent after-sales and technical support (2 years warranty)
