MULTIFUNCTIONAL METER ---- It is a multifunctional meter which include functions of battery capacity meter and hour meter;Display the battery capacity by LED bars, and display the total running hours by LCD screen; Wide operating voltage:12V to 24V,36V,48V to72V.
BATTERY FUEL GAUGE ---- It can be used on lead-acid battery (but not Trojian's)powered device to indicate the remain capacity;there are 10 LED bars with 3 colors(red,green,yellow) to display,10% capacity per bars; 3 voltage pins for 12V to 24V,36V and 48V to72V; It is only lighten the LED bar of current battery capacity whatever connect with key switch or direct connection.
HOUR METER(TOT) ---- It also have function to track how many hours are the engine/machine working, hours read up to 999,999 hours with 0.1/1 hour resolution; TOT hours can be reset, when replace it to another device, it will be restart from 0 also.
INSTALLATION ---- Easy to install;Snap-in design with panel cut-out size:Approx 43×39mm,φ50(1.69x1.54 inch,φ50).
OTHER ---- Waterproof rate: IP65;CE RoHS certification;2-years warranty.
